IC695ALG412 – 12-Channel Strain Gauge/Thermocouple Input Module
Key Features
- ✔ 12 fully isolated differential input channels
- ✔ Supports all major thermocouple types (J, K, T, E, R, S, B, N, C)
- ✔ High accuracy ±0.1% at 25°C
- ✔ Fast 15-120ms configurable update rate
- ✔ Built-in diagnostics for open wire/short circuit detection
Technical Specifications
| Input Types: | ±150mV, ±50mV, Thermocouples |
| Resolution: | 32-bit floating point or 16-bit integer |
| Isolation: | 250VAC continuous |
| Power Consumption: | 3.3V@400mA, 5V@425mA |
| Operating Temp: | 0°C to 60°C (32°F to 140°F) |
Supported Thermocouple Ranges
| Type | Temperature Range |
|---|---|
| Type K | -270°C to 1372°C |
| Type J | -210°C to 1200°C |
| Type T | -270°C to 400°C |
| Type B | 300°C to 1820°C |
Compatibility
- Terminal Blocks: IC694TBB032, IC694TBS032, IC694TBB132, IC694TBS132
- Backplane: RX3i Universal Backplane only
- Software: Machine Edition 5.8+
Environmental Ratings
- Vibration resistant: 10-57Hz @ 1.0G acceleration
- Shock resistant: 15G for 11ms
- Humidity: 5-95% non-condensing
