GE Fanuc IC697MDL752 PLC Module

GE Fanuc IC697MDL752 Series 90-70 Discrete Output Module with 32 Outputs

Technical Specifications

Rated Voltage: 12 VDC

Number of Outputs: 32

Output Groups: 4

Channels per Group: 8

Output Current: 0.5 A per channel / 2 A per group

Output Voltage Range: 10 to 15 VDC

Required Current: 0.25 A

Isolation Voltage: 1500 V

Maximum Inrush Current: 10 A for 20 ms

Response Time: 1 ms on / 1 ms off

Key Parameters Table
