GE Fanuc IC697MDL341 120 VAC Output Module

GE Fanuc IC697MDL341 Series 90-70 12-Point AC Output Module

Product Overview

The IC697MDL341 is a discrete output module in the Series 90-70 lineup.

It operates at 120–240 V AC and has 12 isolated output points.

Each output can connect to separate AC phases for flexible wiring.

Every point supports 2 A and high inrush current up to 10x rated current.

The module handles inductive, resistive, and incandescent loads efficiently.

Each output is fused with a replaceable 3.15 A fuse for protection.

LED indicators show on/off status for points and fuse conditions.

Mechanical keying ensures correct and safe replacement in the field.

Setup does not require DIP switches or jumpers and can be done via programming software.

Technical Specifications

Brand: GE Intelligent Platforms / GE Fanuc

Series: Series 90-70

Part Number: IC697MDL341

Product Type: Discrete Output Module

Rated Voltage: 120–240 V AC

Outputs: 12 isolated points

Output Current/Point: 2 A

Output Current/Module: 16 A

Inrush Current: 10x per point

Fuse Rating: 3.15 A per output

Backplane Current Required: 0.25 A

Frequency: 47–63 Hz

Key Benefits

Flexible wiring with isolated groups for different AC phases.

High inrush current supports a wide range of loads.

LEDs simplify diagnostics and fuse monitoring.

Mechanical keying prevents incorrect installation.

No jumpers or DIP switches needed for setup.
