GE Fanuc IC697MDL340 Output Module

GE Fanuc IC697MDL340 Series 90-70 16-Point AC Output Module

Product Overview

The IC697MDL340 is a discrete AC output module in the Series 90-70.

It operates at 120 V AC and has 16 output points.

Outputs are divided into four isolated groups of four points each.

Each group can act as a separate AC phase for flexible wiring.

Every point supports 2 A with 10x inrush current.

Each group has a 4 A capacity and a 10 A fuse.

The module handles resistive, inductive, and incandescent loads efficiently.

LED indicators show the on/off status of points and fuse condition.

Mechanical keying ensures correct and safe module replacement in the field.

Technical Specifications

Brand: GE Intelligent Platforms / GE Fanuc

Series: Series 90-70

Part Number: IC697MDL340

Product Type: Discrete Output Module

Rated Voltage: 120 V AC

Outputs: 16 points (4 groups of 4)

Output Current/Point: 2 A

Output Current/Group: 4 A

Inrush Current: 10x per point

Backplane Current Required: 0.25 A

Frequency: 47–63 Hz

Key Benefits

Four isolated groups enable flexible AC phase distribution.

High inrush current supports incandescent and inductive loads.

LED indicators simplify troubleshooting and maintenance.

Mechanical keying prevents incorrect module installation.

No jumpers or DIP switches are required for setup.
