GE Fanuc IC695CEP001 CEP Carrier Component

GE Fanuc IC695CEP001 RX3i PROFINET CEP Carrier Module

Product Overview

The IC695CEP001 is a CEP carrier for RX3i PACSystems.

It supports PROFINET version 2.3 (Class A) for high-speed communication.

The module has 2 Ethernet RJ-45 ports and a Micro-B USB port for firmware upgrades.

Voltage range: 19.2 to 30 Volts DC.

Power rating: 5.25 Watts (0.22 Amps) at 24V DC.

One I/O module is supported per station with total 1024 bytes I/O data.

Each station allows 512 bytes for input and output data.

The module features 32 input status bits and 32 output control bits.

It operates in temperatures from 0 to 60°C (32–140°F).

Dimensions: 177.2 x 51 x 35 mm (7 x 2 x 1.3 in).

Technical Specifications

PROFINET Support: Version 2.3 (Class A)

Voltage Range: 19.2 to 30 V DC

Power: 5.25 Watts (0.22 A) at 24V DC

I/O Modules per Station: 1

I/O Data per Station: 1024 bytes (512 bytes input / 512 bytes output)

Ethernet Ports: 2 RJ-45 10/100 Base-TX

USB Connector: 1 Micro-B, USB 2.0 compliant

Dimensions: 177.2 x 51 x 35 mm (7 x 2 x 1.3 in)

Operating Temperature: 0–60°C (32–140°F)

Firmware: Upgrade via USB port

Features: Advanced fault handling and remote node scanning
