GE Fanuc IC694MDL734 125 volt DC Output Module

GE Fanuc IC694MDL734 Output Module

Technical data

Outputs: 6 isolated points

Voltage: 11 to 150 VDC

Load: 1 A per point

Inrush: 7 A for 100 ms

Switch time: 5 to 7 ms

Logic: positive and negative

Isolation: 250 VAC continuous, 1500 VAC for 1 min

Power use: 90 mA from 5 V bus

Temperature: -20 °C to +60 °C

Humidity: 5% to 95% no condense

Storage: -40 °C to +85 °C

Install guide

Use with RX3i racks only

Turn off power before insert

Slide into slot until locked

Use screw clamp for wires

Check LEDs after start

Best done by trained staff
