GE Fanuc | IC694MDL240 – Input Module

IC694MDL240 120VAC Input Module

Key Specs

Works with 0-132VAC power. Normal use at 120VAC. Has 16 separate input channels. Each channel uses 12mA. On state: 74-132VAC. Off state: 0-20VAC. Responds in 30ms or less. Works from 0 to 60°C. Uses 90mA from the backplane at 5VDC.

Where To Use

Factory conveyor safety stops. Motor overload checks. Pump station alarms. Packing line sensors. Furnace door controls. Machine guard switches.

Key Benefits

Blocks power surges. Easy wiring with one common point. Lights show each input status. Handles dirty power. Good for shaky places. Safe for industrial areas.

Works With

All PACSystems RX3i racks. RX3i CPUs. Versamax carriers. Fits in one slot. Uses Machine Edition software.

How To Install

Put in any open slot. Snap top and bottom locks. Connect AC power. Wire devices to points. Use 14-22 wire. Keep 5cm space around.

Shipping

Fedex 2-day. UPS ground. DHL express. Ships from US/UK stock. Tracking number included.

Package Items

One IC694MDL240 module. Setup guide. Mount parts. Safety note card.
