GE Fanuc IC694BEM341 Controller Module

GE Fanuc IC694BEM341 RX3i Bus Controller Module

Product Overview

The IC694BEM341 is a bus controller module for RX3i PACSystems.

It is a FIP controller with universal backplane support and single slot design.

The module transfers 128 Bytes of data per bus cycle.

It has a clock speed of 2.5 MHz and consumes 1.2 Amps.

The controller features a 9-pin male D connector and RS-485 port for communication.

RS-485 allows connection to programming terminals or PCs using Proficy software.

Technical Specifications

Data Exchange: 128 Bytes per cycle

Clock Speed: 2.5 MHz

Power: 1.2 Amps maximum

Voltage: 5V DC

Connector: 9-pin male D connector

Communication: RS-485, datagrams

LED Indicators: 6 LEDs for status and diagnostics
