GE Fanuc IC693MDL330 — Series 90-30 8-Point 120–240VAC Output Module

Product Introduction

IC693MDL330 by GE Intelligent Platforms serves industrial AC output applications.

The module provides 8 outputs in two isolated groups.

It supports 120–240 V AC nominal operation.

Each output delivers 2 A continuous current.

Each output includes an RC snubber for transient protection.

Each group uses a 5 A fuse for group protection.

The module handles high inrush currents for lamps and coils.

Front LEDs show each output status and fuse faults.

Technical Specifications

Brand: GE Intelligent Platforms / GE Fanuc

Series: Series 90-30

Part Number: IC693MDL330

Module Type: Output module

Rated Voltage: 120–240 V AC

Output Voltage Range: 85–264 V AC

Frequency: 50/60 Hz

Outputs: 8 points in two groups of four

Output Current per Point: 2 A

Max Inrush Current per Cycle: 20 A

Minimum Load Current: 100 mA

Max Output Voltage Drop: 1.5 V

Isolation: 1500 V between field and logic
