GE Fanuc IC693MDL310 Output Module

GE Fanuc IC693MDL310 — Series 90-30 12-Point 120VAC Output Module

Product Introduction

IC693MDL310 by GE Intelligent Platforms serves industrial PLC output needs.

The module provides 12 output points in two groups of six.

It operates at 120 V AC nominal voltage.

Each output supports 0.5 A continuous current.

Each group uses a 3 A fuse for protection.

RC snubbers protect outputs from line transients.

The module handles high inrush loads for lamps and coils.

Top LEDs show output status for quick diagnostics.

Technical Specifications

Brand: GE Intelligent Platforms / GE Fanuc

Series: Series 90-30

Part Number: IC693MDL310

Module Type: Output module

Voltage: 120 V AC nominal; 85–132 V AC operating range

Frequency: 50/60 Hz standard

Outputs: 12 points in two groups of six

Output Current per Point: 0.5 A

Output Voltage Range: 85–132 V AC

Output Leakage: 3 mA max at 120 V AC

Inrush Load Current: 5 A for one cycle

Fuse Protection: 3 A fuse per group
