GE Fanuc IC693BEM341 FIP Bus Controller Module | Series 90-30 PLC
Product Overview
The IC693BEM341 is a FIP Bus Controller for Series 90-30 PLCs.
It connects PLCs to FIP networks at 2.5 MHz.
Two 9-pin D-shell FIP ports and one RS-485 port are on the front panel.
Six LEDs indicate Module OK, Run, CD1, CD2, TEN1, and TEN2.
It supports redundancy, slave I/O monitoring, time stamping, messaging, and external configuration.
Requires Series 90-30 CPU version 8.10 or higher.
Configuration uses a Hand-Held Programmer (HHP) or FBCLOAD software.
Main Features
✔ Fast 2.5 MHz FIP network interface
✔ Two 9-pin FIP ports and one RS-485 port
✔ Redundancy and slave I/O management
✔ Time-stamping of up to 1024 Boolean values
✔ Messaging and external configuration reception
✔ Compatible with Series 90-30 PLCs, HHP, and Windows software
Technical Specifications
| Specification | Details |
|---|---|
| Brand | GE Fanuc / Emerson Automation |
| Model | IC693BEM341 |
| Series | Series 90-30 |
| Module Type | FIP Bus Controller |
| CPU Requirement | Series 90-30 CPU version 8.10 or higher |
| Ports | 2 × 9-pin D FIP, 1 RS-485 |
| Backplane Current | 1.2 A max, 800 mA typical |
| Operating Temp | 0–55°C (32–131°F) |
| Status LEDs | Module OK, Run, CD1, CD2, TEN1, TEN2 |
| Transmission Rate | 2.5 MHz |
Installation Notes
Install in Slot 1 of CPU baseplate.
Use HHP or FBCLOAD software for configuration.
Ensure proper ventilation and a clean, dry environment.
Check LEDs to verify proper connection and operation.
