IC693ACC323 Power Supply Module | GE Fanuc Series 90-30
The IC693ACC323 by GE Fanuc is a reliable power supply module for Series 90-30 PLCs. It delivers 5 VDC and 24 VDC relay output with a minimum holdup time of 20 milliseconds. The module supports both AC and DC input voltages.
Technical Specifications
| Brand | GE Fanuc |
| Series | Series 90-30 |
| Part Number | IC693ACC323 |
| Type | Power Supply Module |
| Supported Components | All Series 90-30 PLCs |
| Nominal Voltage | 120/240 VAC or 125 VDC |
| Input Voltage Range | 85–264 VAC / 100–300 VDC |
| Output Power | 5 VDC and 24 VDC relay |
| Output Voltage | 5.0–5.2 VDC (5.1 VDC nominal) |
| Holdup Time | 20 milliseconds minimum |
| LED Indicators | 4 (PWR, RUN, OK, BATT) |
Key Features
- Supports both AC and DC input voltages
- Isolated +24 VDC for powering input modules
- LED indicators for PWR, RUN, OK, and BATT
- Leftmost slot installation recommended
- Input current up to 4 Amps for 250 milliseconds
- Polarity-insensitive DC/AC connections
Installation Notes
- Connect AC: neutral, ground, and hot to top three terminals
- Connect DC: positive and negative wires to top two terminals
- Ensure the module is seated securely in the leftmost slot
- Supports Series 90-30 baseplates and relay modules
FAQ
Q: Can I use this module with other PLC series?
A: No, it is designed for Series 90-30 only.
Q: What is the maximum input voltage range?
A: 85–264 VAC or 100–300 VDC.
Q: How do I know if the module works?
A: Check the four LEDs: PWR, RUN, OK, and BATT.
Q: What about stock and shipping?
A: All units are full new. Stock is ready. Ships in 5 days via DHL. Returns supported within 30 days.
