Discrete Output Module – GE Fanuc IC200MDL742

GE Fanuc IC200MDL742 Output Module

The IC200MDL742 is a discrete output module from GE Fanuc. It has 16 output points for 24VDC systems. This module works in industrial automation.

Key Features

Brand: GE Fanuc

Series: Versamax

Model: IC200MDL742

Output Points: 16 points

Number of Groups: 2 groups

Voltage: 24VDC

Load Current: 0.5A per point

Backplane Current: 150mA

Response Time: 0.5ms

Product Benefits

The IC200MDL742 has short-circuit protection. It also has overcurrent protection. Each group has electrical isolation.

Every output point has LED lights. Green light shows normal operation. Amber light shows overload condition.

This module supports hot swapping. You can replace it without power off. This reduces downtime.

Installation

Mount the module on DIN rail. Install in any direction. Easy to add to existing systems.

Works with other Versamax products. Compatible with other I/O modules.

Questions and Answers

How many output points does this module have?

The IC200MDL742 has 16 discrete output points. They are in 2 groups.

What power supply does it need?

It works with 18-30VDC. Typical voltage is 24VDC. Backplane needs 5VDC power.
