GE Fanuc IC693CPU323 | Series 90-30 10-Slot Embedded CPU Baseplate
The IC693CPU323 is a 10-slot embedded CPU baseplate from the GE Fanuc Series 90-30 PLC line. It integrates an 80188 Turbo CPU running at 10 MHz. The baseplate draws 430 mA at 5 VDC and provides 12 KB battery-backed memory for user programs.
Top Highlights
- 10 I/O slots with embedded CPU for small to medium PLC applications
- Supports up to 320 discrete I/O points
- Analog I/O: 64 AI / 32 AO words
- 340 timers and counters; supports shift register instructions
- Single serial port supporting SNP & SNP-X slave protocols
- Non-expandable; does not support PCM or CCM modules
- Optional EPROM/EEPROM for additional non-volatile memory
- Operating temperature: 0–60°C / 32–140°F
- Panel mounting supported through pre-drilled holes
Technical Specifications
| Brand | GE Fanuc |
| Series | Series 90-30 |
| Part Number | IC693CPU323 |
| CPU Type | 80188 Turbo Embedded CPU |
| Clock Speed | 10 MHz |
| User Memory | 12 KB Battery-Backed |
| Discrete I/O | 320 points max |
| Analog I/O | 64 AI / 32 AO words |
| Timers / Counters | 340 |
| Serial Port | 1 × SNP / SNP-X Slave |
| Voltage Input | 5 VDC |
| Current Load | 430 mA |
| Operating Temperature | 0–60°C / 32–140°F |
| Expansion | None |
| Compatibility | No PCM / CCM modules |
FAQ
Q: Can IC693CPU323 expand with additional slots?
A: No, it supports 10 slots only and cannot use remote racks.
Q: How is memory protected?
A: It has battery-backed RAM. Optional EPROM/EEPROM adds non-volatile storage.
Q: Which communication protocols are available?
A: SNP & SNP-X Slave. Optional modules: Ethernet, FIP, Profibus, GBC, GCM, GCM+.
Q: Stock and return policy?
A: Brand new, in stock, ships within 5 days via DHL. 30-day return policy supported.
