Controller Module GE Fanuc – IC694BEM340

GE Fanuc IC694BEM340 RX3i Bus Controller Module

Product Overview

The IC694BEM340 is a bus controller for RX3i PACSystems.

It supports I/O and datagrams for fast and reliable communication.

It transfers 128 bytes of data per bus cycle.

The module draws 300 mA at 5V DC.

Two front LEDs indicate status: OK for operation, COM for communication.

Up to 8 controllers can be installed in one RX3i system.

It uses chained or twisted-pair cables with resistors for bus termination.

The module supports baud rates of 38.4, 76.8, and 153.6 K.

Technical Specifications

Data Exchange: 128 bytes per cycle

Power: 5V DC, 300 mA

LED Indicators: OK and COM

Communication: I/O and datagrams

Supported Devices: Genius Blocks, VersaMax, Field Stations, HHM

Max Modules per System: 8

Bus Connection: Chained or twisted-pair cable

Bus Termination: Resistors at both ends

Baud Rates: 38.4, 76.8, 153.6 Kbaud
