Analog Output Module GE Fanuc IC670ALG320

GE Fanuc IC670ALG320 Field Control 4-Point Current/Voltage Output Module

Technical Specifications

Brand: GE Fanuc

Series: Field Control

Part Number: IC670ALG320

Module type: 4-point current/voltage source output module

Channels: Four single-ended outputs

Output signals: 0-20 mA, 4-20 mA, 0-10 VDC, 0-12.5 VDC

Analog resolution: 12 bits

Linearity: 1 LSB across ranges

Analog resolution examples: 4.0 µA @ 4-20 mA; 5.0 µA @ 0-20 mA; 2.5 mV @ 0-10 V

ADC conversion: 12-bit, typical

Conversion time: 60 µs per channel (1 MHz clock typical)

Isolation: 1500 VAC for 1 minute; 250 VAC continuous

External power: 20–29 VDC (24 VDC typical)

Bus current draw: 51 mA maximum from BIU

Module current: Standby 80 mA; operating 180 mA (including loop current)

Power dissipation: 1.4 W minimum; 4.3 W maximum

Input types: Isolated and differential supported

Temperature coefficient: ±0.002% per °C typical; ±0.005% per °C maximum
