Analog Input Module GE Fanuc IC200ALG264

GE Fanuc IC200ALG264 Analog Current Input Module

The IC200ALG264 reads current signals for VersaMax PLC systems. This module has 15 inputs for factory machines.

Product Details

• Brand: GE Fanuc (now Emerson)
• Series: VersaMax
• Model: IC200ALG264
• Type: Analog Input Module
• Channels: 15 single-ended
• Current Range: 0-20 mA or 4-20 mA
• Resolution: 15-bit
• Update Rate: 7.5 ms
• Accuracy: 0.3% typical

Power Supply

• Uses PLC backplane power
• Needs 100 mA at 5V
• No external power needed
• Transceivers need extra power
• Green LED shows power status

Input Signals

• 15 current input channels
• Works with 0-20 mA signals
• Works with 4-20 mA signals
• Fast 7.5 ms updates
• High 15-bit resolution

Configuration

• Use jumper for 0-20 mA mode
• Remove jumper for 4-20 mA mode
• Default is 4-20 mA mode
• Easy to change settings
• Quick setup time

Safety Features

• 250V AC continuous isolation
• 1500V AC for 1 minute
• Open wire detection
• Power loss detection
• Use shielded cables

Questions

• How many inputs?
  15 current inputs.
• Current ranges?
  0-20 mA or 4-20 mA.
• Need external power?
  Only for transceivers.
• How to set range?
  Use terminal jumper.
• Update speed?
  7.5 milliseconds.
