GE Fanuc IC697MDL640 Series 90-70 Discrete Input Module
Product Overview
The IC697MDL640 is a discrete input module by GE Fanuc.
It works with positive and negative logic.
The module runs at 125 V DC.
Each input uses 5 mA.
It has 16 input points in 4 groups of 4 points.
One input can be set as an interrupt input.
The input filter can be 1 ms or 10 ms.
LEDs show the on/off status of each input.
The module is keyed for easy replacement.
No jumpers or DIP switches are needed for configuration.
Programming uses Windows or MS-DOS software via SNP or Ethernet.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | GE Fanuc |
| Series | Series 90-70 |
| Part Number | IC697MDL640 |
| Module Type | Discrete Input Module |
| Logic | Positive/Negative |
| Rated Voltage | 125 V DC |
| Inputs | 16 points |
| Input Current | 5 mA |
| Input Voltage Range | -35 to 145 V DC |
| LED Indicators | Yes |
Features
- Supports positive and negative logic for flexible use.
- Input filter selectable at 1 ms or 10 ms.
- One input can act as an interrupt input.
- Mechanically keyed for safe replacement.
- Software configuration, no jumpers required.
- Meets IEC standards for reliability.
