120 VAC Output Module GE Fanuc IC697MDL350

GE Fanuc IC697MDL350 Series 90-70 Discrete Output Module for Industrial Automation

Product Overview

The IC697MDL350 module is a discrete output device by GE Fanuc.

It operates at 120 V AC with 0.5 A per output point.

The module includes 32 output points divided into 4 groups of 8 points.

Each group can connect to a different AC supply phase safely.

Fuses rated at 5 A protect each output group.

The module supports high inrush currents up to 20 times the rated current.

LED indicators show the status of outputs and fuses.

The device is mechanically keyed for easy replacement without configuration errors.

Users can configure I/O references via MS-DOS or Windows software, no jumpers needed.

It works well with indicators, solenoids, and motor starters for industrial loads.

Technical Specifications

Brand: GE Intelligent Platforms/GE Fanuc

Series: Series 90-70

Part Number: IC697MDL350

Module Type: Discrete Output Module

Rated Voltage: 120 V AC

Outputs: 32 points

Output Current/Point: 0.5 A

Output Current/Group: 2 A

Frequency: 47-63 Hz

AC Power: Yes

DC Power: No
