IMI Achieves Milestone with Record-Sized Choke Valves for North Sea Platform
Groundbreaking Delivery for Offshore Industry
IMI has completed delivery of unprecedented production choke valves to an innovative unmanned platform in the North Sea. Industry experts recognize these as the largest production choke valves ever manufactured for offshore applications.
Engineering Specifications and Design Excellence
The 100D DRAG multi-stage control valves measure 20×20 inches with ASME 4500 rating. Manufactured at IMI CCI’s Austrian facility, these valves feature a remarkable 686 barg design pressure. The construction utilizes forged ASTM A182 F22 Cl materials for body and bonnet components. An internal Inconel 625 weld overlay provides superior corrosion protection in harsh marine environments.
Advanced Technology for Extreme Conditions
These valves incorporate IMI’s proprietary DRAG technology, featuring solid tungsten carbide trim construction. This material selection ensures exceptional durability and performance under high-pressure, erosive operating conditions common in offshore production environments.
Successful Testing and Implementation
Following comprehensive factory acceptance testing in Austria, three 100D DRAG valves have been successfully delivered to the North Sea platform. This achievement represents a significant advancement in flow control technology for unmanned offshore operations.
Expert Commentary on Engineering Achievement
Ronald Simon, IMI Principal Engineer for Oil & Gas, emphasized the project’s significance. “The successful production and delivery of these 100D DRAG valves demonstrates our capability to deliver advanced flow control solutions for challenging offshore applications. Designed specifically for unmanned platform operation, these valves meet the highest quality standards essential for reliable, safe, and efficient production in remote locations.”
Strategic Importance for Offshore Operations
Simon further noted the broader implications: “This delivery represents a major engineering milestone for IMI and reinforces our dedication to providing industry-leading flow control solutions for the most demanding offshore applications. The successful implementation of these valves supports the industry’s move toward fully automated, unmanned production facilities.”
Application Scenario: Unmanned Platform Operations
Consider an unmanned production platform in the challenging North Sea environment. The IMI 100D DRAG valves manage critical flow control functions without onsite personnel. Their robust construction withstands extreme pressures and corrosive elements while maintaining precise control over production flows. The valves’ reliability ensures continuous operation, reduces maintenance requirements, and enhances safety in the fully automated facility. This technology enables extended operational periods between maintenance cycles, significantly reducing operational costs and personnel exposure to hazardous environments.
Author’s Insight: The Evolution of Offshore Technology
The development of these record-sized choke valves represents more than just engineering achievement—it signals a fundamental shift in offshore operations philosophy. The move toward unmanned platforms requires equipment that exceeds conventional reliability standards. IMI’s solution addresses this need through material science innovation and precision engineering. The economic implications are substantial: unmanned platforms with such advanced components can reduce operational costs by 30-50% while improving safety metrics by eliminating personnel from hazardous environments. This technological progression enables economically viable production in increasingly challenging offshore fields that would otherwise remain undeveloped.
Frequently Asked Questions (FAQ)
What makes these choke valves unique in the industry?
These 20-inch valves are the largest production choke valves ever manufactured, featuring solid tungsten carbide trim and designed for unmanned platform operation in extreme conditions.
Why is tungsten carbide used in the valve trim?
Tungsten carbide provides extreme durability and erosion resistance essential for handling high-pressure, abrasive flows in offshore production environments.
What are the advantages of unmanned production platforms?
Unmanned platforms significantly reduce operational costs, improve safety by removing personnel from hazardous environments, and enable production in locations previously considered uneconomical.
How does the Inconel 625 overlay enhance valve performance?
The weld overlay provides superior corrosion resistance against harsh marine environments and aggressive production fluids, extending valve service life.
What testing procedures validate valve reliability?
The valves undergo comprehensive factory acceptance testing including pressure testing, functional verification, and material certification to ensure performance under extreme operating conditions.
